型號: VK101,VK102,VK103...
口徑: 2”-24“
壓力: 150LB-600LB
材質: LCB, WCB, CF8,CF8M
使用溫度: -38 to 425 C
應用介質: 導熱油,高溫蒸汽,氫氣等
設計規范:
設計制造:JB/T 11487-2013, API600
結構長度:GB/T 12221, ASME B16.10
連接尺寸:HG/T 20592, ASME B16.25
壓力-溫度: GB/T 9131 ASME B16.34 HG 20592
試驗-檢驗: GB/T13927 GB/T 9092 API 598
氦質譜檢漏:API 602 MSS SP-117
設計特點:
1. 采用雙層波紋管結構,閥門結構合理,更加緊湊;
2. 本公司設計制造的雙波紋管閘閥安裝高度較同類產品下降20%~30%;
3. 采用雙層波紋管結構,閥門在開關過程中對波紋管的受力減小,
且受力更均勻,延長其使用壽命;
4. 采用雙層波紋管,密封更加可靠。閥門經氦檢漏,實現零泄漏,
特別使用于易燃、易爆、劇毒介質的管路,環保又安全;
5. 采用直通式結構,優化流道設計,介質過流阻力小,流量系數大,使用更節能;
6. 采用填料、雙波紋管及閥桿等多層密封,使閥門達到真正的零泄漏
Application: For flammable and explosive
working conditions, e.g. hot oil, hydrogen, etc.
Design features.
1. the use of double bellows structure, the valve structure is reasonable and
more compact.
2. the installation height of the double bellow gate valve designed and
manufactured by our
company is 20%~30% lower than that of
similar products.
3. the use of double bellows structure, the valve in the process of opening and
closing the
force on the bellows is reduced, and the
force is more uniform, extending its service life.
4. the use of double-layer bellows, more reliable sealing. The valve is
leak-tested by helium
to achieve zero leakage.Especially used in flammable, explosive, highly toxic media pipeline,
environmental protection and safety.
5. adopt straight-through structure, optimize the flow channel design, the medium
overflow resistance is small, the flow
coefficient is large, use more energy-saving.
6. the use of packing, double bellows and stem multi-layer seal, so that the
valve to
achieve a true zero leakage
